Best Seller Ranger Boat Blank Switch Panel 9859203 | Z522D Comanche Illuminated

Boat part number 7101996 is a new OEM illuminated blank switch panel for a Z522D Comanche model Boat from Ranger Boats, part number 9859203 .

This OEM blank switch panel is constructed out of black marine grade plastic, and measures approximately 10 7/8″ L x 4 5/8″ W overall. Requires a cutout of 4 1/2″ D, and has (4) 1/8″ Dia. mounting holes, spaced 3 1/8″ apart center on center. Has (15) cutouts that measures approximately 7/8″ Dia. and (2) 1 1/2″ Dia. on bottom cover. Illuminates with a set of white LED lights in the rear of the panel, illuminating through the white lettering on the face of the panel. Light connection has (2) wire leads: (1) red and (1) black.

Features the following cutouts:

• Horn
• Bilge
• NAV. LT.
• Anchor
• LIVEWELL FILL MAN
• LIVEWELL FILL TIMED
• LIVEWELL RECIR. MAN
• LIVEWELL RECIR. TIMED
• BAITWELL MAN
• BAITWELL TIMED
• 1
• 2
• 3
• 4
• INT LT

Specifications:

• Boat Manufacturer: Ranger Boats
• Model Z522D Comanche
• Part Number: 9859203
• Material: Marine Grade Plastic
• Color: Black
• Finish: Matte
• Overall Dimensions: 10 7/8″ L x 4 5/8″ W
• Cutout(s): (15) 7/8″ Dia. / (2) 1 1/2″ Dia.
• Mounts: (4) 1/8″ Dia. Holes Spaced 3 1/8″ Apart Center On Center
